  1. Cooling is Coming- Nissan Titan XD Intercooler, Part 2: Final Prototype

    Cooling is Coming- Nissan Titan XD Intercooler, Part 2: Final Prototype

    Preparation is an elusive concept. No matter how much time you spend getting ready, you find yourself at the event remembering everything you did not bring. Perhaps this applies more to me, the least prepared individual of all. I constantly find myself in situations where if I had prepared, I could have been ahead of the eight-ball rather than feeling like it was tumbling down a hill after me. For instance, I once showed up to a track day without a tire pressure gauge, rookie mistake. Since then, I have learned the merits of taking some extra time to be prepared.

    The Titan XD is no different. The truck is relatively new, so many won't choose to modify it just yet, but we have a feeling that the XD has big things in its future. That is why we decided to be prepared with our intercooler.

    Render</body> " width="640" height="360">
    Continue Reading »
  2. Conquering the Catch Can - Part 3: Final Prototype Testing

    Conquering the Catch Can - Part 3: Final Prototype Testing

    If you remember from our last post about the Titan XD catch can, we ran into some challenges with the first and second prototypes. Since then we have perfected our design, so without further delay, let's look at our final prototype for testing.

    Final Prototype

    With the check engine light vanquished, our last update left us with a slightly different hurdle to climb. A buildup of condensation in the system had us a tad worried about possible freezing in the winter. Little did we know that the solution was right in the Titan's engine bay. One of the benefits of working on a larger truck is that there is more room under the hood to work with. We used this to our advantage and decided to relocate the can to another spot in the engine bay - one that would see more heat. The idea is that extra heat introduced to the catch can will burn off a good deal of the moisture and prevent freezing of the can. A fine theory, but let's see it in practice.

    Continue Reading »
  3. Conquering the Catch Can - Part 2: Prototype Update

    Conquering the Catch Can - Part 2: Prototype Update

    If you remember from our last post about the Titan XD catch can, we ran into some challenges with the first prototype. Since our existing catch can design did not agree with the Titan, it was back to the drawing board for our lead engineer, Dan.

    Updated Design

    Our standard catch can when installed on the Titan was generating a code causing the truck to go into limp mode. The cause of the code stemmed from our standard catch can being too restrictive for the Titan's beefy Cummins engine. This is not surprising, given the 50 micron filter and smaller design of the can, which was originally designed for gasoline-powered cars. This catch can design functions beautifully on smaller turbo engines such as the Focus and Fiesta, as well as larger American V8s in the new-generation Camaro SS and Mustang GT. It just might not be suitable for the turbo diesel V8 in our

    Continue Reading »
  4. Defending the Titan- Coolant Filtration Kit R&D, Part 2: Final Prototype

    Defending the Titan- Coolant Filtration Kit R&D, Part 2: Final Prototype

    Last time, we took an in-depth look at coolant filtration kits and how they can benefit our Titan. We gave you a sneak peek at what the final bracket for the Titan XD coolant filtration kit will look like. If you missed out on that you can check out the whole post on our engineering blog.

    Finalizing the brackets

    These brightly colored brackets were created with the help of 3D printing. This is just one of our rapid prototyping techniques that helps us create accurate prototypes the first time around. This allows us to bring great-looking AND great-fitting products to you in much less time.

    Prototype bracket for the Titan XD coolant filtration kit
    Continue Reading »
  5. Cooling is Coming- Intercooler R&D, Part 1: Stock Evaluation

    Cooling is Coming- Intercooler R&D, Part 1: Stock Evaluation

    We have been working on the Titan XD for quite some time now. We have gone through a variety of products like the intercooler pipe kit, coolant filtration kit, and exhaust. Now we are down to the bread and butter of our Titan XD parts: the intercooler.

    When we begin projects, we like to start by evaluating the stock component and looking for areas where we can make improvements. The stock intercooler in the Titan is fairly sizeable and features cast aluminum end tanks, which we don't normally see on stock intercoolers. Nissan has started off on the right foot with this intercooler. Still, we are confident that we can take it a few steps further with our intercooler design.

    Stock Nissan Titan XD intercooler
    Stock Nissan Titan XD intercooler
    Continue Reading »
  6. Cooling the Cummins- Radiator R&D, Part 1: Stock Evaluation

    Cooling the Cummins- Radiator R&D, Part 1: Stock Evaluation

    Since Mishimoto's inception, we have grown to become more than just a radiator manufacturer; have expanded to offer many other performance parts for a variety of applications. For the Titan alone we already offer a several products, including an intercooler pipe and boot kit, exhaust, and coolant filtration kit. We have not, however, forgotten our roots. That being said, we have begun developing a radiator for our Nissan Titan XD.

    What improvements will we make?

    The stock radiator is sizeable compared to other stock units we have seen, but we still found some areas where we can improve on the factory design.

    Stock Titan XD radiator
    Stock Titan XD radiator

    We plan to increase the core thickness and create a fully

    Continue Reading »
  7. Treating the Titan- Exhaust R&D, Part 2: Exhaust Fabrication

    Treating the Titan- Exhaust R&D, Part 2: Exhaust Fabrication

    We are back with a much needed update on the Titan XD exhaust. Since our last post covering the stock Titan XD exhaust, we've come up with a design of our own.

    The first step in bringing our prototype from design to reality was to create a jig to use for fabrication. We started by taking measurements from the Titan, then fired up the waterjet, and sliced our largest jig to date. It had to be sizeable enough to accommodate the four-inch piping designated for the Titan.

    Jig for Titan XD exhaust prototype
    Jig for Titan XD exhaust prototype

    Jig for</body> " width="426" height="640">
    Continue Reading »
  8. Defending the Titan- Coolant Filtration Kit R&D, Part 1: Prototype Testing

    Defending the Titan- Coolant Filtration Kit R&D, Part 1: Prototype Testing

    Personally, I am a huge Nissan fan, but I try not to be too biased when it comes to working on Nissan projects. I do, however, remember how excited I was when the new Titan development vehicle first rolled into our headquarters in all its glory. I found myself pricing options on the Internet and weighing my student loan debt with the prospect of a shiny new toy. So with a love like this, it makes sense to protect it.

    When developing products, we consider several factors. We evaluate possible improvements to the factory setup of a vehicle, to make more power, or to solve a problem with factory components. Also where we can create products to protect the vehicle. For all of the Nissan Titan fans who waited patiently for their trucks to arrive and are now enjoying them, it is important to us to protect your investment. The Mishimoto coolant filtration kit is definitely a protect-your-investment product.

    How does it work?

    A coolant filtration system will

    Continue Reading »
  9. Refining a Titan- Intercooler Pipe Kit R&D, Part 2: Prototype Fabrication

    Refining a Titan- Intercooler Pipe Kit R&D, Part 2: Prototype Fabrication

    In our last post, we ended with a rendering of the Nissan Titan XD intercooler pipes and the jig that we plan to use to fabricate them. Since then, we began fabricating our prototypes and testing fitment.

    Before we could begin welding our prototypes, we first had to fabricate our jig. With the help of the trusty waterjet, we sliced the pieces for the jig and began assembling them.

    Titan XD Intercooler piping jig
    Titan XD Intercooler piping jig

    Titan</body> " width="640" height="426">
    Continue Reading »
  10. XD Induction Hose R&D, Part 2: The Working Prototype

    XD Induction Hose R&D, Part 2: The Working Prototype

    Some exciting developments are brewing in the world of induction hoses! We recently received into our R&D facility our first shipment of samples for the 2016+ Nissan Titan XD, and they are all looking great.

    3D modeling Titan XD performance parts
    3D modeling Titan XD performance parts

    Our tube's design is not overly complex, and it will be an awesome addition to the engine bay of this Cummins-powered Nissan. The design of the factory tube is interesting because of the type of bend it has. The orientation of the airbox opening does not have an even plane for a straight-through design that can just loop over to the throttle body. The opening angles out a bit, facing more in the direction of the truck's firewall. What results is an interesting

    Continue Reading »
