- Features
PRODUCT FEATURES
- Direct fit for 2016+ Mazda MX-5
- Highly aggressive intake tone under acceleration
- Smooth design eliminates restrictions and improves airflow
- Aluminum intake pipe includes CNC-machined MAF housing
- Powder-coated black airbox keeps unwanted hot air from entering the air filter
- Functions with the stock intake duct which supplies cold air to intake filter
- Mishimoto High-Flow Oiled Air Filter receives maximum airflow from the front of the vehicle
- Available with a polished, wrinkle black, or wrinkle red pipe
- Mishimoto Lifetime Warranty
DESCRIPTION
The Mazda MX-5 is known as the ultimate driver’s car. It’s designed to be light and nimble, making for a rewarding driving experience. The Mishimoto 2016 MX-5 intake creates a sound that enhances this driving experience even more while looking amazing in your engine bay. The MX-5 air intake pipe is available in a polished, wrinkle black, or wrinkle red finish to match whatever style you’re going for.
The stock intake duct is utilized to supply cold air to the intake filter, while the CNC-machined MAF housing makes for accurate sensor readings. This ND MX-5 air intake features a high-flow filter to let your engine breathe, as you rip down back roads with the gas pedal mashed to the floor. As with all our 2016 MX-5 parts, the Mishimoto Lifetime Warranty ensures high-quality parts and performance for the life of your MX-5 intake.PURCHASE INCLUDES
(1) Aluminum Intake Pipe
(1) High-Flow, Oiled Filter
(1) Steel Airbox
(1) Silicone Sound Imposer Hose
(1) Silicone Fresh Air Duct Hose
(1) Silicone Coolant Overflow Tank Hose
(3) Worm Gear Clamps
Mounting Hardware
Mishimoto Lifetime Warranty
NOTES
Will only fit the US model 2.0L Miata with the SkyActiv engine. Will not fit the 1.5L found in other markets.INSTALLATION TORQUE SPECS 22 in-lbs (2.5N*M) recommended for all worm-gear clamps. These clamps have an operating range of 18-27 in-lbs 2-3N*M. Do not exceed the maximum torque rating of 27 in-lbs (3N*M).
- TECH SPECS
VEHICLE SPECS
Engine Codes PE-VPS Chassis Codes ND Fits 2016+ Mazda MX-5 PRODUCT SPECS
Pipe Diameter 2.75" (70mm) O/D Airbox Material Steel Oiled Filter 38 g of oil on filter Pipe Material Mandrel-Bent Aluminum Oil Color Red Air Filter Part Number MMAF-2756S - ENGINEERING
Final Prototype Installed – ND Miata Intake, Part 5
February 16, 2016
As we finally round the end of the long and arduous testing and data collection process, it’s time to test the fitment of the final prototype to ensure there are no issues before we kick off full-scale production. A lot of effort has gone into designing and engineering this kit, and it has been rewarding … Continue reading Final Prototype Installed – ND Miata Intake, Part 5 →
Testing and Results – ND Miata Intake, Part 4
February 08, 2016
We finally have an update for the Miata intake project! With our prototype now in working order, we were finally able to hook up our ND Miata to our dynamometer and get some pulls underway. At this point in the process, we knew we’d want to play around with some other design ideas while the … Continue reading Testing and Results – ND Miata Intake, Part 4 →
Prototype Sound Clips – ND Miata Intake, Part 3
November 30, 2015
We want to be absolutely sure we are designing an intake that will provide what the MX-5 enthusiasts crave from such a product – sound, throttle response, looks, and of course, driving feel and performance. Our prototype is still in the testing process so we do not have dyno results quite yet. Instead, to hold … Continue reading Prototype Sound Clips – ND Miata Intake, Part 3 →
