Key Features
Features
Direct fit for the 2016+ Mazda MX-5 Miata
Single can mounts in line with the PCV system to separate oil from air using a 50 micron bronze filter
Features integrated drain valve and hose for easy service
Billet 6061 aluminium can sealed with Viton™ O-rings
Robust, application-specific bracket mounts the can in a serviceable location without interfering with aftermarket strut tower bars
Includes pre-molded hoses for simplified installation
Defends intake system and essential engine components from oil blow-by
CNC-machined aluminium barbed fittings ensure a sturdy connection between lines and can
Catch can has an 88 ml capacity for longer servicing intervals
Internal air diverter increases air turbulence to improve oil separation
Helps maintain proper octane levels to reduce potential detonation
Filter and can are fully serviceable
US Patent Numbers D884,760, ZL 201830621732.1, ZL 202120175368.7
With the release of the new 2015 Mazda MX-5, the Mishimoto engineers are hard at work looking for ways to improve engine efficiency. They created this new direct-fit MX-5 oil catch can system to help protect the heart of your MX-5 from harmful blow-by.
Direct injection engines, like the one in the 2015 MX-5, suffer from accelerated carbon build up due to the lack of port injection, which washes the valves with fuel during engine operation. The engineers saw a significant coating of oil build up while examining the intake manifold. The oil was coming from the PCV system, which contributed to carbon accumulation and a decrease in octane levels. Mishimoto's new MX-5 catch can system helps to prevent this blow-by from reaching the intake, resulting in a cleaner running engine.
Mishimoto's Mazda MX-5 oil catch can kit features Mishimoto's 2-port Compact Baffled Oil Catch Can with a bronze filter and internal baffle to better separate the oil from the crankcase vapors. Two direct-fit silicone hoses and an application-specific bracket make for a quick and simple installation. Like all Mishimoto ND MX-5 parts, this catch can kit comes with the Mishimoto Lifetime Warranty!
Read more
TECH SPECS
More Information
Applications
2016+ Mazda Miata
Chassis Codes
ND
Installation Notes
22 in-lbs (2.5NM) recommended for all worm-gear clamps. These clamps have an operating range of 18-27 in- 2-3NM. Do not exceed the maximum torque rating of 27 in-lbs (3NM).
Note
After installation, Mishimoto recommends checking the contents of the baffled catch cans every 500 miles until a baseline is established. Oil blow-by accumulation will vary with ambient temperatures and driving conditions. It is important that the contents of the can do not rise above the internal baffle.
After installation, Mishimoto recommends checking the contents of the baffled catch cans every 500 miles until a baseline is established. Oil blow-by accumulation will vary with ambient temperatures and driving conditions. It is important that the contents of the can do not rise above the internal baffle.
