£610.00 (Incl. VAT)
  • Fits 2011+ Ford Ranger 3.2L Diesel*
  • Increases core volume by 146% over stock intercooler
  • Increases external fin surface area by 159% over stock intercooler
  • Durable bar-and-plate core and cast aluminium end tanks provide greater resistance to heat and pressure
  • Additional features below
Features

PRODUCT FEATURES

  • Fits 2011+ Ford Ranger 3.2L Diesel*
  • Increases core volume by 146% over stock intercooler
  • Increases external fin surface area by 159% over stock intercooler
  • Durable bar-and-plate core and cast aluminium end tanks provide greater resistance to heat and pressure
  • Available in sleek silver or stealth black powder coated finish
  • Mishimoto Lifetime Warranty

DESCRIPTION

The 2011+ Ford Ranger 3.2L diesel is one of the most capable small trucks on the planet and it deserves a cooling system that's equally capable. That’s why Mishimoto has developed a performance intercooler that’s as capable as the Ranger itself.

This Mishimoto performance intercooler features a high-quality bar-and-plate core that’s precision TIG-welded to durable cast-aluminium end tanks. This design gives our intercooler increased durability and resistance to heat and pressure. The Mishimoto intercooler also boasts a 146% increase in core volume and 159% increase in fin surface area over the stock intercooler for even more efficient cooling. The Mishimoto Ranger 3.2L diesel intercooler is available in a stealth black or sleek silver powder coated finish to suit any look.

This Mishimoto 2011+ Ford Ranger 3.2L Diesel Performance Intercooler includes mounting brackets for easy installation and is backed by our Mishimoto Lifetime Warranty for a lifetime of performance.

PURCHASE INCLUDES

(1) Mishimoto Performance Intercooler
(4) Mounting Brackets
Mounting Hardware
Mishimoto Lifetime Warranty

NOTES

* Trimming of the intercooler shrouding is required to fit this intercooler.

TECH SPECS

VEHICLE SPECS

MakeFord
Engine Codes 3.2L Duratorq
Fits 2011+ Ford Ranger XL w/ 3.2L Diesel
2011+ Ford Ranger XLS w/ 3.2L Diesel
2011+ Ford Ranger XLT w/ 3.2L Diesel
2011+ Ford Ranger FX4 w/ 3.2L Diesel
2011+ Ford Ranger Wildtrak w/ 3.2L Diesel

PRODUCT SPECS

Core Thickness 76 mm
Coating Powder Coated
Outlet 53 mm
Core Length 70 cm
Core Height 25 cm
Inlet 53 mm
Construction Bar-and-plate
WARRANTY

Mishimoto Automotive (“Mishimoto”) warrants their products under this lifetime limited warranty policy (“Warranty Policy”). This Warranty Policy applies solely to: (i) Mishimoto Products purchased directly from Mishimoto or Mishimoto authorised dealers (each a “Mishimoto Product” and collectively, the “Mishimoto Products”) and (ii) the original purchaser of such Mishimoto Product (“Purchaser”). This Warranty Policy is non-transferable and all claims under this Warranty Policy must be accompanied by the original sales receipt. The terms and conditions of this Warranty Policy are subject to change by Mishimoto at any time without notice.

For our complete warranty policy, please click here.

Mishimoto Lifetime Warranty on ALL Products
