  • Direct fit for 2008-2010 Ford 6.4L Powerstroke
  • Stacked-plate design for maximum durability and efficiency
  • Increases core volume by 63% over stock
  • Increases surface area by 121% over stock
  • Adjustable brackets allow you to fit the cooler with larger radiators or intercoolers
  • Fits with Mishimoto radiator and intercooler
  • Mishimoto Lifetime Warranty

Heavy loads are no match for a 2008–2010 Ford 6.4L Powerstroke equipped with the Mishimoto 6.4L Transmission Cooler. The Ford 6.4L Powerstroke is renowned for its towing capabilities. With up to 16,000 lbs of towing capacity, it’s certainly no slouch. But every powertrain has its limits. With the Mishimoto 6.4L Powerstroke transmission cooler, you’ll be able to push those limits knowing that your transmission is protected.

The 17-row stacked-plate cooler provides a 121% larger surface area over stock and increases core volume by 63%. That all adds up to a road and dyno-proven 20°F drop in transmission fluid temperature at the cooler outlet.

No modifications are necessary for installation, and, just like all Mishimoto 6.4L Powerstroke parts, this cooler comes with the Mishimoto Lifetime Warranty.

Mishimoto Automotive (“Mishimoto”) warrants their products under this lifetime limited warranty policy (“Warranty Policy”). This Warranty Policy applies solely to: (i) Mishimoto Products purchased directly from Mishimoto or Mishimoto authorised dealers (each a “Mishimoto Product” and collectively, the “Mishimoto Products”) and (ii) the original purchaser of such Mishimoto Product (“Purchaser”). This Warranty Policy is non-transferable and all claims under this Warranty Policy must be accompanied by the original sales receipt. The terms and conditions of this Warranty Policy are subject to change by Mishimoto at any time without notice.

For our complete warranty policy, please click here.

EVEN MORE COOL ITEMS

TECH SPECS

SKU MMTC-F2D-08SL

Core Height 8.9"

Rows 17

Note This kit includes a leveling spacer for use with Mishimoto's 6.4L radiator. This spacer should be used on the driver's side mounting bracket where the cooler bolts onto the radiator. This is only needed when installing the cooler with the Mishimoto 6.4L radiator.

Core Thickness 1.25"

Core Length 33.5"

Engine Codes 6.4L Super Duty

Chassis Codes F-250
F-350
F-450

Overall Height 15.5"

Overall Length 33.5"

Purchase Includes (1) Mishimoto Stacked Plate Transmission Cooler
(1) Transmission Cooler Hose
(1) Leveling spacer for use with Mishimoto Radiator
(2) Direct-fit Brackets
Mounting Hardware
Mishimoto Lifetime Warranty

Also Fits 2008–2010 Ford F-250 w/ 6.4L Powerstroke
2008–2010 Ford F-350 w/ 6.4L Powerstroke
2008–2010 Ford F-450 w/ 6.4L Powerstroke

Engineering Blog

Redefine the Limits – Transmission Cooler R&D, Part 2: Design

Redefine the Limits – Transmission Cooler R&D, Part 2: Design

March 22, 2019

The pre-sale for this trans cooler is now live! Click here to check it out! As Dan inched our 6.7L F-350 onto the trailer, the October sun beat down onto the black asphalt. It wasn’t even 11:00AM and the thermometer read almost 80°F; hot for October in Delaware, but perfect for transmission cooler testing. I … Continue reading Redefine the Limits – Transmission Cooler R&D, Part 2: Design →
