Coolant Filter Kit, fits Nissan Titan XD 2016+

Add your photo

Coolant Filter Kit, fits Nissan Titan XD 2016+

Model

MMCFK-XD-16

As low as £248.36 (Incl. VAT)

Only %1 left

Add to Wish List

$Login or create an account to for this product.

Key Features

Features

Direct fit for 2016+ Nissan Titan XD
6061 anodized aluminum filter mount
One-piece application-specific silicone hoses available in black, blue, or red
Filters solid particles from your truck's coolant
Extends the life of your oil cooler, water pump, EGR cooler, coolant, and other critical components
No modification of factory hoses
Includes Wix coolant filter
Ball valve shut-offs included
Installs in under 45 minutes
Mishimoto Lifetime Warranty

See all features

Installation Difficulty: Easy

Key Features

Direct fit for 2016+ Nissan Titan XD
6061 anodized aluminum filter mount
One-piece application-specific silicone hoses available in black, blue, or red
Filters solid particles from your truck's coolant
Extends the life of your oil cooler, water pump, EGR cooler, coolant, and other critical components
No modification of factory hoses
Includes Wix coolant filter
Ball valve shut-offs included
Installs in under 45 minutes
Mishimoto Lifetime Warranty

See all features

Product Description

Mishimoto has released a direct-fit coolant filter kit for the 2016+ Nissan Titan XD to help prevent your truck from being a victim of factory cooler clogs and failure. The application-specific mounting bracket mounts a precision CNC-machined 6061 aluminum filter mount and Wix coolant filter to the passenger side battery mount, an ideal location for easily removing the filter. This Titan XD coolant filtration system is routed in parallel with the flow path of your coolant system and allows a small amount of coolant to be filtered with each pass. The Mishimoto engineers also included two brass ball valves with this kit to help make changing the filters a clean process. The two silicone coolant hoses have been designed as once piece hoses to reduce any possibility of leaks and are offered in black, blue, or red to complement any engine bay. This coolant filter kit installs in under 45 minutes with no modification necessary. Protect your truck from harmful particles and help to extend the life of your trucks oil cooler, water pump, EGR cooler, coolant, and other critical engine components with the Mishimoto Titan XD coolant filter kit. Like all Mishimoto Titan performance parts, this Titan XD Coolant Filter kit comes with the Mishimoto Lifetime Warranty.

More Information
Engine Codes	IS-V
Installation Notes	22 in-lbs recommended for all worm gear clamps. These clamps have an operating range of 18-27 in- 2-3NM. Do not exceed the maximum torque rating of 27 in-lbs
Applications	2016-2019 Nissan Titan XD 5.0 Cummins
Note	Mishimoto recommends changing the coolant filter after the first month, again after 3 months, and then every year after that, depending on driving conditions. Because each engine was cast differently, there will be a different amount of debris collected. Utilizes WIX filter #24070.

Downloads

Downloads

Installation Guides

Installation Guides

(Size: 3.4 MB)

Installation Guides

Purchase Includes

Application-Specific Mounting Bracket
Silver, Anodized 6061 Aluminum Filter Mount
Coolant Filter
Direct-Fit Silicone Hoses
Brass Ball Valves
Worm Gear Clamps
Plastic Straight Barbed Fitting
Mounting Hardware
Mishimoto Lifetime Warranty

Note:

Mishimoto recommends changing the coolant filter after the first month, again after 3 months, and then every year after that, depending on driving conditions. Because each engine was cast differently, there will be a different amount of debris collected. Utilizes WIX filter #24070.

ENGINEERING

Defending the Titan- Coolant Filtration Kit R&D, Part 2: Final Prototype

November 23, 2016

Last time, we took an in-depth look at coolant filtration kits and how they can benefit our Titan. We gave you a sneak peek at what the final bracket for the Titan XD coolant filtration kit will look like. If you missed out on that you can check out the whole post on our engineering blog.

Finalizing the brackets

These brightly colored brackets were created with the help of 3D printing. This is just one of our rapid prototyping techniques that helps us create accurate prototypes the first time around. This allows us to bring great-looking AND great-fitting products to you in much less time.

Prototype bracket for the Titan XD coolant filtration kit

Defending the Titan- Coolant Filtration Kit R&D, Part 2: Final Prototype

Defending the Titan- Coolant Filtration Kit R&D, Part 1: Prototype Testing

September 30, 2016

Personally, I am a huge Nissan fan, but I try not to be too biased when it comes to working on Nissan projects. I do, however, remember how excited I was when the new Titan development vehicle first rolled into our headquarters in all its glory. I found myself pricing options on the Internet and weighing my student loan debt with the prospect of a shiny new toy. So with a love like this, it makes sense to protect it.

When developing products, we consider several factors. We evaluate possible improvements to the factory setup of a vehicle, to make more power, or to solve a problem with factory components. Also where we can create products to protect the vehicle. For all of the Nissan Titan fans who waited patiently for their trucks to arrive and are now enjoying them, it is important to us to protect your investment. The Mishimoto coolant filtration kit is definitely a protect-your-investment product.
