Ford Mustang EcoBoost Hot-Side Intercooler Pipe Kit, 2015+

Ford Mustang EcoBoost Hot-Side Intercooler Pipe Kit, 2015+
Ford Mustang EcoBoost Hot-Side Intercooler Pipe Kit, 2015+
Ford Mustang EcoBoost Hot-Side Intercooler Pipe Kit, 2015+
Ford Mustang EcoBoost Hot-Side Intercooler Pipe Kit, 2015+
Not Available
Reward Points You will earn 295 Points for purchasing this product.
Installation Difficulty

Add to Build List
  • Direct fit for the 2015+ Ford Mustang EcoBoost
  • Replaces weak stock hot-side plastic intercooler pipe
  • CNC-machined BPV flange allows for quick install of stock or stock-style BPVs
  • Installs in under 30 minutes
  • Lightweight, mandrel-bent aluminium pipe
  • Fits both stock and Mishimoto Performance Intercoolers
  • Available with a polished or wrinkle black finish
  • Includes Mishimoto Silicone couplers and Mishimoto T-Bolt Clamps
  • Mishimoto Lifetime Warranty
  • CARB EO #: D-759

Looking for a way to improve spool-up, increase power potential, and improve engine bay aesthetics on your EcoBoost Mustang? Mishimoto has you covered with a new hot-side intercooler pipe designed specifically for the 2015+ Ford Mustang EcoBoost. This EcoBoost Mustang kit features 63.5mm mandrel-bent aluminium piping for smooth airflow, and four-layer silicone couplers with heat-resistant embedded fibres for improved tolerance against heat and pressure. This 2015 Mustang kit also includes high-quality stainless steel T-bolt clamps for consistent and reliable holding power. Installation on your 2015 Mustang is simple, requires no modification to any parts in the engine bay, and can be completed in under 30 minutes. The precision CNC-machined BPV flange allows you to retain the stock EcoBoost Mustang BPV. The Mishimoto Mustang EcoBoost Hot-Side Intercooler Pipe Kit is available in either polished or wrinkle black finish and like our entire line of Mustang parts, includes the Mishimoto Lifetime Warranty.

Mishimoto Automotive (“Mishimoto”) warrants their products under this lifetime limited warranty policy (“Warranty Policy”). This Warranty Policy applies solely to: (i) Mishimoto Products purchased directly from Mishimoto or Mishimoto authorised dealers (each a “Mishimoto Product” and collectively, the “Mishimoto Products”) and (ii) the original purchaser of such Mishimoto Product (“Purchaser”). This Warranty Policy is non-transferable and all claims under this Warranty Policy must be accompanied by the original sales receipt. The terms and conditions of this Warranty Policy are subject to change by Mishimoto at any time without notice.

For our complete warranty policy, please click here.

EVEN MORE COOL ITEMS

TECH SPECS

Installation Torque Specs 27 in-lbs (3N*M) recommended for all t-bolt and constant tension t-bolt clamps. These clamps have an operating range of 18-35 in-lbs (2-4N*M). Do not exceed the maximum torque rating of 35 in-lbs (4N*M).

Purchase Includes (1) Aluminum Pipe w/ CNC-Machined BPV Flange
(2) Silicone Couplers
(1) 2.0” T-Bolt Clamp
(3) 2.75” T-Bolt Clamps
Mishimoto Lifetime Warranty

Pipe Diameter 2.5"

Constant Tension T-Bolt Clamps Specs (1) 2.0” T-Bolt Clamp
(3) 2.75” T-Bolt Clamps

Engine Codes 2.3L EcoBoost

Chassis Codes S550

Fits 2015+ EcoBoost Mustang

Make Ford

Engineering Blog

Mustang EcoBoost Intercooler Pipe R&D, Part 3: Final Pipe Design and Test Fit

Mustang EcoBoost Intercooler Pipe R&D, Part 3: Final Pipe Design and Test Fit

May 18, 2015

Interested in picking up our Mustang EcoBoost Intercooler Pipe Kit? Check out more details on our product page linked below! Mishimoto Ford Mustang EcoBoost Intercooler Pipe Kit After putting some final touches on our pipe design in 3D modeling software, we concluded the design phase of this project. With only inspection of our final prototype … Continue reading Mustang EcoBoost Intercooler Pipe R&D, Part 3: Final Pipe Design and Test Fit → The post Mustang EcoBoost Intercooler Pipe R&D, Part 3: Final Pipe Design and Test Fit appeared...

Read More

Mustang EcoBoost Intercooler Pipe R&D, Part 2: 3D Models and BPV Port Prototyping

Mustang EcoBoost Intercooler Pipe R&D, Part 2: 3D Models and BPV Port Prototyping

May 08, 2015

Interested in picking up our Mustang EcoBoost Intercooler Pipe Kit? Check out more details on our product page linked below! Mishimoto Ford Mustang EcoBoost Intercooler Pipe Kit 3D Pipe Models As with all our projects, we would be using 3D modeling software (Solidworks) to put our final design into both 3D and drawing forms. Not … Continue reading Mustang EcoBoost Intercooler Pipe R&D, Part 2: 3D Models and BPV Port Prototyping → The post Mustang EcoBoost Intercooler Pipe R&D, Part 2: 3D Models and BPV Port Prototyping appeared first on...

Read More

Mustang EcoBoost Intercooler Pipe R&D, Part 1: Stock Piping Evaluation

Mustang EcoBoost Intercooler Pipe R&D, Part 1: Stock Piping Evaluation

April 02, 2015

Interested in picking up our Mustang EcoBoost Intercooler Pipe Kit? Check out more details on our product page linked below! Mishimoto Ford Mustang EcoBoost Intercooler Pipe Kit The factory-equipped intercooler piping for the Mustang EcoBoost (EB) is a bit of a disappointment. Assuming you have popped the hood … Continue Reading ›› The post Mustang EcoBoost Intercooler Pipe R&D, Part 1: Stock Piping Evaluation appeared first on Mishimoto Engineering Blog.

Read More
